Liquid Filtration, Clarification, and Purification: The Stainless Steel Plate and Frame Filter Solution

Versatile Applications

• Pharmaceuticals: Ideal for filtering injection solutions and intravenous fluids, ensuring sterility and purity.
• Food & Beverage: Used in brewing, juice production, and dairy processing to clarify liquids and remove impurities.
• Water Treatment: Facilitates the purification of water, making it suitable for industrial or potable use.
• Chemical and Environmental: Effective in handling chemical solvents, electroplating solutions, and wastewater treatment.

Customizable Filtration Precision

• Variable Filter Media: Select from a range of filter materials (e.g., filter cloths, papers, membranes) to achieve specific filtration grades, from coarse to fine.
• Adjustable Structure: Modify the number of filter plates according to production volume, ensuring scalability for small-scale research or large-scale manufacturing.
• Enhanced Filtration: When paired with pre-filtration layers or filter aids (such as diatomaceous earth, bentonite, or activated carbon), it delivers ultra-clean filtrate.

Key Advantages

1. Efficient Operation: Minimizes liquid loss, offers high flow rates, and simplifies the filtration process.
2. User-Friendly Design: Features easy disassembly, cleaning, and maintenance. The flat, threaded mesh structure of filter plates prevents media damage, extending their lifespan and reducing long-term costs.
3. Energy-Efficient: Comes with a stainless steel liquid transfer pump that requires low power consumption, optimizing energy usage.
4. Mobility: Equipped with rubber wheels, allowing effortless movement within production facilities.

Advanced Features of the Plate and Frame Filter

• Sealed Filtration: Ensures closed-loop processing, meeting the stringent requirements for purification, sterilization, and deactivation of activated carbon.
• Large Filtration Area: Enables high-volume processing, making it a preferred choice for pharmaceutical, chemical, and food industries.
• Innovative Design: Inspired by paper plate filters, the refined plate and frame filter supports multiple filter media types, accommodating diverse liquid characteristics.
• Smart Operation:
  • Dual Inlet/Outlet: Boosts flow speed and maintains even pressure distribution.
  • Visual Inspection: Two glass sight glasses allow real-time monitoring of liquid clarity before and after filtration.
  • Pressure Monitoring: A pressure gauge at the inlet provides clear feedback on operating conditions.
  • Sampling & Venting: The sampling valve at the outlet enables easy post-filtration sampling and system venting.
  • Quick-Connect Fittings: Simplify installation and cleaning, while ISO-standard valves and pipes ensure seamless integration with existing production lines.
