Wenzhou Suote Pharmaceutical Processing Equipment Pharmaceutical Processing Equipmentmade in China
Company Advantages
· The designers working for Wenzhou Suote Pharmaceutical And Chemical Engineering Co.,Ltd is globally famous.
· The quality assurance program followed by us ensures that the product is in complete compliance with the international quality standards.
· Wenzhou Suote is here to provide the best experience for pharmaceutical processing equipment consumers by offering quality products, services and outstanding support.
use
This concentrator is suitable for the concentration of liquid materials such as traditional Chinese medicine, Western medicine, starch sugar, food and dairy products, and is especially suitable for low-temperature vacuum concentration of heat-sensitive materials.
Drawing Description of Hot Reflux Extraction Concentrator
1. Extracting tank
2.Sight glass
3. Vacuum switcher
4. Cooler
5. Hot backset current condenser
6. Butterfly valve
7. Defoamer machine
8. Reflux pipe
9. Butterfly valve
10. Concentrating Evaporator
11. Heater
12. Sight glass
13. Vacuum buffer tank
14. Wacuum pump in water annular style
SN II series dual-effect concentrator Equipment features
1. Energy saving benefits, calculated based on the SN II-1000 type, save about 2,500 tons of steam, about 70,000 tons of water, and about 60,000 kilowatt hours of electricity annually, which is equivalent to RMB 80,000-100,000 (compared with single effect).
2. This concentrator adopts a natural circulation evaporation method with negative pressure external heating. It has a fast evaporation speed and a large concentration specific ratio, which can reach 1.1-1.3 (general traditional Chinese medicine ointment).
3. This concentrator adopts two-effect simultaneous evaporation, and the secondary steam is used. The total energy consumption is reduced by 40% compared with the single-effect concentrator. One year's energy saving fee can recover the entire investment of this concentrator.
4. Multifunctional operation features: (1) The alcohol concentration can be recovered around 80%: (2) The first and second effects can be combined repeatedly to collect the paste; (3) Intermittent and continuous feeding can be performed.
5. The parts in contact between this concentrator and materials are made of stainless steel and comply with GMP requirements. The appearance is beautiful. The heater and evaporator are equipped with thermal insulation. The outer shell of the thermal insulation is made of stainless steel plate, and the surface is treated with mirror and matte finish.
According to customer requirements, we launched a first-effect two-effect energy-saving concentrator with paste collection. During the normal concentration process, close the valve connecting the nozzle and circulation pipe between the first-effect heating chamber and the evaporation chamber. The material enters the first-effect evaporation chamber and is heated by the jacket of the first-effect evaporation chamber. It is concentrated under normal pressure or under reduced pressure in the first-effect evaporation chamber to obtain a concentrated paste with a higher specific gravity (1.35-1.45).
Product parameters
JN model series multifunctional alcohol concentrator Equipment features
1. Alcohol recovery: The recovery capacity is large, and the vacuum operation method is adopted to improve the process flow of the equipment. The recovery rate can reach 95%, making the alcohol loss rate less than 5%. Energy consumption is reduced by 30%, and it is an energy-saving equipment with small investment and high recycling efficiency.
2. Concentrated liquid materials: This equipment adopts external heating natural circulation and vacuum negative pressure evaporation methods, which can have a fast evaporation speed and a concentration specific gravity of up to (1.3); liquid materials can be concentrated without foam in a fully sealed environment. Use this equipment to concentrate The medicinal liquid that comes out is pollution-free and has a strong medicinal flavor. Easy to clean, just open the upper and lower heater covers. It is simple to operate, occupies a small area, and has a beautiful appearance. The heater, evaporator, and insulation are completely shipped from the factory. The parts in contact with the liquid material are all made of stainless steel AISI304. The insulation is made of polyurethane foam or pearl cotton, and the outer surface is frosted and matte. Processed in compliance with GMP pharmaceutical standards.
product display
Company Features
· Dominating a vital position in the industry, Wenzhou Suote Pharmaceutical And Chemical Engineering Co.,Ltd keeps at the top when it comes to the R&D and manufacturing of pharmaceutical processing equipment.
· Our management team is comprised of experts with years of experience in the pharmaceutical processing equipment industry. They are excellent in design, development, and production to push the whole team to work best.
· We are trying hard to cut carbon footprint during production. We do materials recycling work, engage in waste management, and actively conserve energy or resources. In doing these, we hope we can contribute to environmental protection.
Application of the Product
Wenzhou Suote's pharmaceutical processing equipment can be applied to different fields and scenes, which enables us to meet different requirements.
Guided by the actual needs of customers, Wenzhou Suote provides comprehensive, perfect and quality solutions based on the benefit of customers.
Product Comparison
pharmaceutical processing equipment in Wenzhou Suote has the following advantages, compared with same kind of products in the market.
Enterprise Advantages
Our company has a professional and technical team, and regularly trains the team to improve their comprehensive strength. They can provide technical support for production and research and development of the products.
In order to respond quickly to customers' demands, our company has established a set of efficient and perfect service system, which promotes standardized service in all links, such ad before, during and after sales.
Wenzhou Suote always follows the corporate spirit of 'stick to yourself, dare to challenge and never say never'. We take 'standardization, integrity, innovation' as our business philosophy. We strive to meet consumers' needs and give play to self-advantage, so as to provide better products and more comprehensive services.
Through the development of years, Wenzhou Suote has finally opened up a road of production scale, management standardization, product features.
Wenzhou Suote continuously develops ourselves in the fierce competition based on the advantages of technology and talents. This enables us to expand the sales network, from the domestic market to neighboring countries and regions.
